Avalon Mist is a full overlay frameless kitchen cabinet line that has a light grey painted finish which brings out a modern style of the cabinets. adjustable plywood shelving, matching interior and exterior finish, and lastly the soft-closing hinges.
Best price guarantee
We are confident you get the best deal possible with us. All our cabinets are backed by the 90 Day Best Price Guarantee. If you find the same product from another retailer for less, we will beat the competitor price even after you placed the order with us. See full details and limitations.
Shipping time
Avalon Mist pre-assembled cabinets leave the warehouse in 5-7 business days after placing an order. Standard transit time after shipping is 2-6 business days.
We offer an extensive selection of different cabinet lines. The cabinet specifications vary depending
on a particular product. Please contact us if you need additional information.
General specifications
Color & finish
Grey stain
Door and drawer profile
Shaker style
Wood species
Birch
Sides color
Cabinet sides are unfinished, finishing skins are required for exposed sides.
Drawers
⅝" solid wood dovetail drawer with ⅜” plywood bottom. Tandem plus Blumotion (#554H5330B01) 80% extension concealed drawer runners.
Door hinges
Compact Blumotion (#38N355B.06) soft-close mechanism integrated in concealed six-way adjustable hinges. The soft closing mode can be turned off. Soft closing door hinge example: Video
Interior color
Clear coated natural wood color.
Particle board
No particle board is used in this cabinet line construction
Doors
5/8" thick solid wood door frame. Center panel is MDF (Medium Density Fiber Board) with wood veneer. Drawer front is 5/8" thick solid slab MDF. Why do we use MDF?
Cabinet construction
½" unfinished plywood side panels grooved into face frame. ½" select veneered plywood back with a natural finished interior. See interior color section for information on interior finish.
¾" thick plywood toe kick. Matching ¼" toe kick cover to be ordered separately.
Base corner supports
Wood corner blocks
Center stile
No center stile on cabinets up to 36" wide
Door and drawer stoppers
Clear adheisive bumpers
Hinge side
Hinges on single door wall and base cabinets are located on the right side by default. In most cases, they can be reversed to the opposite side. Reversing the cabinet hinge position may require pre-drilling small holes.
Cabinets with full overlay doors come with a small clearance between doors/drawers and cabinet edges. If a cabinet is located next to a wall or other surface (e.g. refrigerator panel), it is recommended to add at least 1/4" spacer for an additional clearance to allow doors/drawers operate smoothly. Some applications will require a bigger clearance depending on hardware and other project requirements. Use a scribe molding or wall/base fillers to fill the gaps. Generally the additional spacing is not required in between cabinets unless they are different depth (e.g. a 12" deep wall cabinet next to a 24" deep pantry). See an example
About Specifications
Cabinet specifications dimensions are typically converted from metric to inches and rounded. It may cause variations in measurements. Room lighting and screen settings will affect cabinet color appearance. Please order a sample for accurate product color information. Contact us with any questions about cabinet styles and specifications.
Wall cabinet with 1 door and 2 shelves. This cabinet can be modified into a wall spice cabinet. The spice cabinet hardware is available in the Cabinet Organizers section.
Wall cabinet with 1 door and 2 shelves. This cabinet can be modified into a wall spice cabinet. The spice cabinet hardware is available in the Cabinet Organizers section.
Wall cabinet with 1 door and 3 shelves. This cabinet can be modified into a wall spice cabinet. The spice cabinet hardware is available in the Cabinet Organizers section.
Wall cabinet with 1 door and 3 shelves. This cabinet can be modified into a wall spice cabinet. The spice cabinet hardware is available in the Cabinet Organizers section.
Wall cabinet with 1 door and 3 shelves. This cabinet can be modified into a wall spice cabinet. The spice cabinet hardware is available in the Cabinet Organizers section.
Wall cabinet with 1 door and 3 shelves. This cabinet can be modified into a wall spice cabinet. The spice cabinet hardware is available in the Cabinet Organizers section.
Diagonal wall corner cabinet with 2 shelves. This cabinet takes up 24" of space on each side of the corner. The visible cabinet front part is approximately 17" wide. This cabinet is also available with a glass door, see the Accessories tab for more details.
Diagonal wall corner cabinet with 3 shelves. This cabinet takes up 24" of space on each side of the corner. The visible cabinet front part is approximately 17" wide. This cabinet is also available with a glass door, see the Accessories tab for more details.
Diagonal wall corner cabinet with 3 shelves. This cabinet takes up 24" of space on each side of the corner. The visible cabinet front part is approximately 17" wide. This cabinet is also available with a glass door, see the Accessories tab for more details.
Wall blind corner cabinet with 1 door and 2 shelves. This cabinet takes up more space than its width, the recommended space is 27". It can be used as left or right, requires a wall filler (not included). The door section is 8-3/4" wide. The stile width is 6". Opening is 7-3/4" wide. See the product page for an installation diagram example.
Wall blind corner cabinet with 1 door and 2 shelves. This cabinet takes up more space than its width, the recommended space is 27". It can be used as left or right, requires a wall filler (not included). The door section is 8-3/4" wide. The stile width is 6". Opening is 7-3/4" wide. See the product page for an installation diagram example.
Wall blind corner cabinet with 1 door and 2 shelves. This cabinet takes up more space than its width, the recommended space is 27". It can be used as left or right, requires a wall filler (not included). The door section is 8-3/4" wide. The stile width is 6". Opening is 7-3/4" wide. See the product page for an installation diagram example.
Wall blind corner cabinet with 1 door and 2 shelves. This cabinet takes up more space than its width, the recommended space is 33". It can be used as left or right, requires a wall filler (not included). The door section is 14-1/2" wide. The stile width is 6". Opening is 13-3/4" wide. See the product page for an installation diagram example.
Wall blind corner cabinet with 1 door and 2 shelves. This cabinet takes up more space than its width, the recommended space is 39". It can be used as left or right, requires a wall filler (not included). The door section is 20-1/2" wide. The stile width is 6". Opening is 19-3/4" wide. See the product page for an installation diagram example.
Wall blind corner cabinet with 1 door and 2 shelves. This cabinet takes up more space than its width, the recommended space is 39". It can be used as left or right, requires a wall filler (not included). The door section is 20-1/2" wide. The stile width is 6". Opening is 19-3/4" wide. See the product page for an installation diagram example.
Wall blind corner cabinet with 1 door and 2 shelves. This cabinet takes up more space than its width, the recommended space is 39". It can be used as left or right, requires a wall filler (not included). The door section is 20-1/2" wide. The stile width is 6". Opening is 19-3/4" wide. See the product page for an installation diagram example.
Wall blind corner cabinet with 2 doors and 2 shelves. This cabinet takes up more space than its width, the recommended space is 45". It can be used as left or right, requires a wall filler (not included). The door section is 13-1/4" wide. The stile width is 6". Opening is 25-7/8" wide. See the product page for an installation diagram example.
Wall microwave cabinet with 2 doors. Side panels are 3/4" thick flush with face frame. Cut opening on the job side. The max microwave cut-out is 28" wide x 17 1/2" high.
Wall microwave cabinet with 2 doors. Side panels are 3/4" thick flush with face frame. Cut opening on the job side. The max microwave cut-out is 28" wide x 17 1/2" high.
Wall microwave cabinet with 2 doors. Side panels are 3/4" thick flush with face frame. Cut opening on the job side. The max microwave cut-out is 28" wide x 17 1/2" high.
Base cabinet with 1 door, 1 drawer, and 1 shelf. This cabinet can be modified into a waste container pullout base cabinet. The waste container pullout hardware is available in the Cabinet Organizers section.
Base cabinet with 1 door, 1 drawer, and 1 shelf. This cabinet can be modified into a waste container pullout base cabinet. The waste container pullout hardware is available in the Cabinet Organizers section.
